• 24V DC severe duty winch rated at 22.000 lb
• Waterproof and dustproof construction
• Potted contactor and motor provide complete protection from water penetration and allow dependable operation in up to 1.8 meters of water.
• Rubber seals at motor and gear housing joints for independent water protection
• Double lip and spring seal at drum support racks
• Industrial duty remote control with twist-on connector to provide total protection from water.
• Water-proof remote control with thermometric LED indicator alerts from motor
• Tough aluminum die cast housings withstand
• U.S. Germany, U.K. France, etc patented mechanical cone brake holds the full load without slippage.
• Corrosion resistance 720hr
• Meets international standards of CE Machinery Directive 2006/42/CE, CE Electromagnetic Compatibility Directive 2014/30/EU, and SAE J706 Surface Vehicle standard 2003-08 rev

Part Number

• PN 282210 (24V)

Rated line pull

• 9,980 kg / 22,000 lb (single line)

    Line speed ( 1st layer): 9.0 mpm / 29.5 fpm 30 A at 24V no load
                                        1.4 mpm / 4.6 fpm 330 A at 24V full load

• Motor: 5,220 w / 7.0 hp 24V series wound
• Gear train: 3-stage planetary 343:1
• Clutch (freespooling): Rotating ring gear
• Brake (outside the drum): Automatic, full load  CBS (Cone Brake Structure)
• Winch construction: Aluminum die cast housings with steel drum
• Drum size:102 mm x 254L mm (4” x 10”L)
• Control: Waterproof remote with thermometric indicator LED w/ 5 m (17') cord
• Rope type: 6 × 29 - IWRC. (Breaking strength 126.4 kN)
• Rope size: 12.7 mm x 25 m (1/2” x 82’)
• Mounting bolt pattern: 304 mm x 114.3 mm (12” x 4.5”)
•                                         304 mm x 165 mm (12" x 6.5")
• Mounting: Foot forward mounting only
• Foot forward mounting can meet SAE J706
