• Provides an answer to the health and safety recommendations for manual lifting.
• High efficient low amp. draw and sealed permanent magnet motor.
• Lightweight and compact design is ideal for easy installation.
• Mechanical cone brake and permanent motor dynamic brakes together for safe, controlled load.
• Waterproof industrial remote control with 5 m lead.
• Full metal 3 stage planetary gear train for greater pulling force.
• Submersible sealed contactor handles high amps and allows higher duty cycle.
• In compliance with standard of ASME B30.5 for D/d≥18 and rope safety factor ≥3.5

Part numbers

751321 (12V)
751375 (24V)

Rated load: 544 kg / 1,200 lb

Line speed (at 1st layer of rope):

12V : 7.4 mpm / 24.3 fpm 30A at no load
          5.5 mpm / 18.0 fpm 130A at full load

24V : 5.9 mpm / 19.4 fpm 15A at no load
          5.0 mpm / 16.4 fpm 50A at full load

• Motor: 900 w / 1.2 hp 12/24V permanent magnet
• Gear ratio: 3-stage planetary gear 216:1
• Brake (outside the drum): Mechanical cone brake and permanent motor dynamic brakes together
• Hoist construction: Aluminum die cast housings with cast iron drum
• Drum size: 89 x 73 mm (3.5” x 2.9")
• Control: Remote control with 5 m (17') lead
• Rope type: Galvanized aircraft A7 x 19
• Rope size: 4.8 mm x 18.3 m (3/16" x 60')
• Mounting bolt pattern: 114 x 101.6 mm (4.5” x 4”)
• Hoist weight including rope 15.3kg / 33.7 lb

International Standard of compliance

• CE Machinery Directive 2006/42/EC
• CE EMC Directive 2014/30/EU
• ASME B30.5
  • (Exceeds Australian compliance requirements)
